Page 11 - Green Pin Product Catalogue 2019_EN

Conditions
Certificate types 2.1, 2.2, 3.1, MTC a, DNV GL 2.7-1 a, DNV GL 2.7-1 b, DNV GL 0377, DNV GL 0378, DGUV,
ABS PDA, ABS MA and CE can be supplied at no extra charge. For all other certificates, additional costs will
be charged.
Free of Charge: INTRODUCTION

2.1 2.2 3.1 MTC a DNV GL 2.7-1 a DNV GL 2.7-1 b DNV GL 0377 DNV GL 0378 DGUV CE ABS PDA ABS MA

With additional Charges:
MTC b LROS MPI a MPI b US a US b DNV GL CG3 BL

On request the proof load test certificates can be supplied surveyed by an official classification society, such as
LROS, DNV GL, BV, ABS or any other officially certified inspection body. Specific details of certificate availability
can be found in each product chapter. Please verify your certification requirements at the time of order. For
more information and specifications, see the table below for an overview of the different test methods.
Test Test Test
method type description Document
Visual Non The products are inspected and approved by our QC-department. 2.1
inspection Destructive The products are inspected and approved by our QC-department, 2.2
stating the results of non-specific inspection.
Material Destructive The material of the products is inspected. This includes chemical 3.1
specific composition and mechanical properties at component level.
inspection
Proof Non Samples of a production batch of products are proof load tested. MTC a
Load Destructive Products are not individually tested.
test All products of a production batch are individually proof load tested. MTC b
Magnetic Non Samples of a production batch of products are Magnetic Particle MPI a
Particle Destructive Inspection (M.P.I.) tested in accordance with EN 10228-1.
inspection Products are not individually tested.
All products of a production batch are individually Magnetic Particle MPI b
Inspection (M.P.I.) tested in accordance with EN 10228-1.
Ultrasonic Non Samples of a production batch of products are Ultrasonic Inspection US a
inspection Destructive (U.S.) tested in accordance with EN 10228-3.
Products are not individually tested.
All products of a production batch are individually Ultrasonic Inspection US b
(U.S.) tested in accordance with EN 10228-3.
Break Destructive Samples of a production batch are break load tested. BL
Load
test
