TURNBUCKLES Green Pin EE Turnbuckle
Turnbuckle with eye-eye end-fitting, generally to ASTM F1145-92

drop forged high tensile steel SAE 1035 or 1045
• Material:
• Safety factor:
MBL equals 5 x WLL
generally to ASTM F1145-92
• Standard:
formerly U.S. Federal Specification FF-T-791b
hot dipped galvanized
• Finish:
• Certification:
2.1 2.2 3.1 MTC

working diameter take length a CE length length diameter width length length weight
load thread up closed open inside inside closed each
limit position position position
a b c d e f g h
t inch inch mm mm mm mm mm mm mm kg
0.54 3 /8 6 292 428 183 10 13 29 49 0.48
1 1 /2 6 325 455 193 12 18 36 58 0.81
1 1 /2 9 400 608 270 12 18 36 57 1.07
1 1 /2 12 476 760 346 12 18 36 57 1.29
1.59 5 /8 6 380 503 203 14 21 45 79 1.33
1.59 5 /8 9 455 656 280 14 21 45 78 1.61
1.59 5 /8 12 531 808 356 14 21 45 78 1.96
2.36 3 /4 6 413 532 214 17 26 54 89 2.03
2.36 3 /4 9 490 685 291 17 26 54 89 2.47
2.36 3 /4 12 564 837 367 17 26 54 88 2.9
G-6311
2.36 3 /4 18 718 1143 519 17 26 54 89 3.94
3.27 7 /8 12 604 870 377 20 32 61 101 4.31
3.27 7 /8 18 756 1174 529 20 32 61 101 5.51
4.54 1 6 498 604 234 24 37 76 118 4.35
4.54 1 12 649 909 387 24 37 76 117 5.75
4.54 1 18 801 1215 539 24 37 76 117 7.27
4.5 1 24 952 1518 692 24 37 76 116 7.52
1
6.9 1 /4 12 712 985 385 29 47 91 145 9.28
6.9 1 /4 18 862 1287 537 29 47 91 144 11.1
1
91
12.1
1
6.9
6 9.71 1 /4 24 1015 1592 690 29 47 106 144 14.2
32
12
401
1023
756
156
1
55
1 /2
9.71 1 /2 18 916 1335 553 32 55 106 160 15.8
1
1
9.71 1 /2 24 1065 1636 706 32 55 106 158 17.1
12.7 1 /4 18 1020 1396 577 38 61 120 197 23.1
3
12.7 1 /4 24 1171 1703 730 38 61 120 196 26.3
3
16.8 2 24 1264 1784 748 46 69 147 230 40.7
1
27.2 2 /2 24 1430 1934 802 51 80 165 274 64
34 2 /4 24 1450 1988 802 57 84 178 284 88
3
INFO CAD

continued on next page >
