DNV GL Master Link Assembly
• Material: alloy steel, grade 8 LINKS
• Safety Factor: MBL equals 5 x WLL
• Standard: DNV 2.7-1, EN 12079-2 and EN 1677-4
• Finish: painted orange
• Temperature range: -20°C up to +200°C
• Certification: 2.1 2.2 3.1 MTC b DNV GL 2.7-1 a
working diameter length width diameter length width weight
load inside inside inside inside each
limit
a b c d e f
t mm mm mm mm mm mm kg
4.1 16 150 75 14.5 125 60 1.3
5.8 22 270 140 16 150 75 3.8
8.83 26 270 140 20 140 70 5.3
11.8 28 270 140 20 140 70 5.9
P-6820 17.1 32 270 140 26 190 102 9.7
23 36 270 140 28 190 100 11.9
28.1 40 280 155 32 270 140 18.6
38.3 45 320 175 36 270 140 25.4
45 50 350 195 40 260 130 32.3
65 60 410 220 50 350 195 62
100 75 450 250 65 410 220 116
In inch
working diameter length width diameter length width weight
load inside inside inside inside each
limit
a b c d e f
t inch inch inch inch inch inch lbs
4.1 5 /8 5 /32 2 /16 9 /16 4 /32 2 /8 2.87
29
3
29
15
15
5
29
5.8 7 /8 10 /8 5 /2 3 /4 5 /32 2 /16 8.38
1
8.83 1 /32 10 /8 5 /2 25 /32 5 /2 2 /4 11.68
1
3
1
5
1
3
1
3
5
1
11.8 1 /32 10 /8 5 /2 25 /32 5 /2 2 /4 13.01 7
17.1 1 /4 10 /8 5 /2 1 /32 7 /32 4 /32 21.39
1
1
5
1
15
1
3
1
15
13
23 1 /32 10 /8 5 /2 1 /32 7 /32 3 /16 26.24
5
15
28.1 1 /16 11 /32 6 /32 1 /4 10 /8 5 /2 41.01
1
5
1
1
9
3
25
5
38.3 1 /32 12 /32 6 /8 1 /32 10 /8 5 /2 55.99
13
7
1
19
45 1 /32 13 /32 7 /16 1 /16 10 /4 5 /8 71.21
1
31
1
11
25
9
65 2 /8 16 /32 8 /32 1 /32 13 /32 7 /16 136.69
11
5
21
31
25
3
15
5
27
100 2 /16 17 /32 9 /32 2 /2 16 /32 8 /32 255.74
21
23
1
