HOOKS Green Pin Self Locking Hook S EN 1677-3 GR8
®
Grade 8 swivel self locking hook EN 1677-3

• Material:
• Safety factor: alloy steel, grade 8, quenched and tempered
MBL equals 4 x WLL
• Standard : EN 1677-3
• Finish: painted yellow (J), red (R) or white
• Temperature range: -40°C up to +200°C
• Certification: 2.1 2.2 3.1 MPI b DGUV

• Note: equipped with needle roller thrust bearing to enable rotation under load
for chain working length length width width thickness width width length diameter thickness weight
diameter load inside inside opening outside each
limit
XLE a b c d e f g h i j
mm inch t mm mm mm mm mm mm mm mm mm mm kg
5 - 6 3 7 1.12 122 32 32 32 16 26 77 192 12 6 0.78
c /16 - /32
5
i 7-8 1 /4 - /16 2 148 39 37 43 23 29 92 231 14 8 1.39
j b 10 3 /8 3.2 183 46 48 47 32 35 111 282 16 11 2.56
13 1 /2 5.4 214 57 58 61 37 45 142 336 21 14 4.56
16 5 /8 8.2 269 65 73 74 39 56 185 416 25 17 9.37
ah
18 - 20 3 /4 12.8 303 87 82 88 51 63 207 480 25 22 12.7
d
f
e
g

Green Pin Self Locking Hook S GR8
®
Grade 8 swivel self locking hook

• Material: alloy steel, grade 8, quenched and tempered
• Safety factor: MBL equals 4 x WLL
• Finish: painted yellow (J), red (R) or white
• Temperature range: -40°C up to +200°C
9 • Certification: 2.1 2.2 MPI b

• Note: equipped with needle roller thrust bearing to enable rotation under load

for chain working length length width width thickness width width length diameter thickness weight
diameter load inside inside opening outside each
limit
a b c d e f g h i j
GKE mm inch t mm mm mm mm mm mm mm mm mm mm kg
5
7 - 8 1 /4 - /16 2 122 33 32 32 17 25 77 192 12 6 0.77
10 3 3.2 148 40 37 43 24 29 92 231 14 8 1.38
c /8
i 13 1 /2 5.4 185 47 48 47 32 34 111 282 16 11 2.56
j b 16 5 /8 8.2 213 60 58 61 37 46 142 339 21 14 4.58
18 - 20 3 /4 12.8 268 62 73 74 43 57 185 417 25 17 9.51
22 7 /8 15.5 305 88 82 90 52 62 207 480 25 22 12.85
ah
d
f
e
g
