Page 163 - Green Pin Product Catalogue 2019_EN

Green Pin Sling Hook E GR10
®
Grade 10 eye sling hook HOOKS

• Material: alloy steel, grade 10, quenched and tempered
• Safety factor: MBL equals 4 x WLL
• Finish: painted blue
• Temperature range: -40°C up to +200°C
• Certification: 2.1 2.2 3.1 MPI b DGUV

• Note: from 10 t without flat part
for chain working length diameter width thickness width diameter width length width thickness weight
diameter load inside opening eye outside each
limit eye outside
UCSO a b c d e f g h i j
mm inch t mm mm mm mm mm mm mm mm mm mm kg
6 7 1.4 84 23 26 15 20 43 72 114 10 6 0.28
f /32
b 8 9 /32 - /16 2.6 103 26 30 20 24 51 87 139 12 8 0.52
5
i 10 3 /8 4 128 35 33 24 29 65 106 172 15 10 1.09
j
13 1 /2 6.8 152 41 37 32 39 77 133 209 18 12 1.94
16 5 10.3 190 52 44 40 44 94 165 255 21 16 3.51
a h /8
c 20 3 /4 16 237 60 61 49 62 115 208 327 28 21 7.1
e
d
g

Green Pin Sling Hook CL GR10
®
Grade 10 clevis sling hook

• Material: alloy steel, grade 10, quenched and tempered
• Safety factor: MBL equals 4 x WLL
• Finish: painted blue
• Temperature range: -40°C up to +200°C
• Certification: 2.1 2.2 3.1 MPI b DGUV 9

for chain working length width width thickness width width width length diameter weight
diameter load opening outside outside outside pin each
limit
UCSC a b c d e f g h i
mm inch t mm mm mm mm mm mm mm mm mm kg
6 7 /32 1.4 75 7 26 15 20 28 72 108 8 0.29
f
b 9 /32 1.95 95 9 30 20 24 32 87 136 10 0.58
8 5 2.6 95 9 30 20 24 32 87 136 10 0.58
i /16
10 3 /8 4 113 12 33 24 29 42 106 164 13 1.11
13 1 /2 6.8 138 15 37 32 39 54 133 208 16 2.12
a h
c 16 5 /8 10.3 161 19 44 40 44 68 165 240 20 3.78
20 3 /4 16 198 22 61 49 62 82 208 305 24 7.49
e
d
g

163
