HOOKS Green Pin Self Locking Hook E GR10
®
Grade 10 eye self locking hook

• Material:
• Safety factor: alloy steel, grade 10, quenched and tempered
MBL equals 4 x WLL
• Finish: painted blue
• Temperature range: -40°C up to +200°C
• Certification: 2.1 2.2 3.1 MPI b DGUV

for chain working length diameter width thickness width width width length width thickness weight
diameter load inside opening outside outside each
limit eye
UXLO a b c d e f g h i j
mm inch t mm mm mm mm mm mm mm mm mm mm kg
6 7 /32 1.4 111 24 32 16 26 47 77 147 11 7 0.51
f
5
b 8 9 /32 - /16 2.6 134 29 43 23 29 57 92 176 14 7 0.91
i
j 10 3 /8 4 168 35 47 32 35 69 111 219 17 10 1.79
13 1 /2 6.8 199 46 61 37 45 87 142 264 20 13 3.36
16 5 /8 10.3 247 59 74 43 56 111 185 328 26 16 7
a h
20 3 /4 16 283 70 90 52 61 126 205 372 28 20 9.22
c
e
d
g

Green Pin Self Locking Hook CL GR10
®
Grade 10 clevis self locking hook

• Material: alloy steel, grade 10, quenched and tempered
• Safety factor: MBL equals 4 x WLL
• Finish: painted blue
• Temperature range: -40°C up to +200°C
9 • Certification: 2.1 2.2 3.1 MPI b DGUV

for chain working length width width thickness width width width length diameter weight
diameter load opening outside outside pin each
limit
a b c d e f g h i
UXLC mm inch t mm mm mm mm mm mm mm mm mm kg
6 7 /32 1.4 92 7 32 16 26 28 77 131 8 0.49
9 1.95 116 9 43 23 29 32 92 161 10 0.91
f /32
b 8 5 /16 2.6 116 9 43 23 29 32 92 161 10 0.91
10 3 4 143 12 47 32 35 42 111 200 13 1.77
i /8
13 1 /2 6.8 167 15 61 37 45 54 142 242 16 3.33
16 5 /8 10.3 201 19 74 43 54 68 185 293 20 6.75
a h
20 3 /4 16 234 23 90 52 61 82 205 339 24 9.57
c
e
d
g
