LIFTING EYES LIFTING EYES

Applications

Eye bolts and eye nuts are used for lifting machines,
appliances or any other objects which cannot be lifted

by hand or by fork lift truck.

Range

®
®
Green Pin offers eye bolts and nuts in grade 8 and stainless steel. To complement the Green Pin assortment,
Van Beest offers a wide range of other lifting eye bolts, eye nuts and lifting points, from M6 up to M100, with
WLLs from 0.07 t up to 40 t.
Design

Grade 8 lifting points are made from alloy steel. The threading is standard metric. Eye bolts and eye nuts are
drop forged from C15 steel.
Each eye bolt and eye nut is generally marked with:
• Working Load Limit - e.g. 0.7 t, valid for in-line lifting; or 1.5t
• manufacturer’s symbol - e.g. Bs or GP
5
• thread diameter - e.g. M16 or /8"-11UNC
• traceability code - e.g. A1 or HA
• steel grade - C15 or 8 (8 only on AL, EL, ADA and PAS)
• item code - e.g. EL, AL, ADA, OL
• CE conformity code - CE

Finish

The eye bolts and eye nuts can be painted or electro-galvanized. Grade 8 lifting points are painted and
supplied with a protective cover over the threads. Do not remove the cover until use. Grade 8 products were
®
®
painted yellow or red under the Excel brand. However, grade 8 products under the Green Pin brand will be
painted white. Grade 10 products are painted blue and will remain so.
10
Certification
Specific details of certificate availability can be found on each product page. Please verify your certification
requirements at the time of order.
