LOADBINDERS Green Pin Ratchet Loadbinder HK
Ratchet type loadbinder with hooks

• Material:
drop forged/cast steel
• Safety factor:
MBL equals 3.5 x Lashing Capacity
• Finish:
painted red or green
• Certification:
2.1 2.2

length
chain
length
lashing
load
size handle diameter thickness length length closed width take-up capacity proof minimum weight
each
breaking
barrel
open
P-7130 position position load
a b c d e f g
mm mm mm mm mm mm mm mm mm t t t kg
8 - 10 385 65 15 255 735 575 12 160 2.45 4.9 8.62 4.32
10 - 13 385 65 15 255 760 595 16 165 4.175 8.35 14.97 5.73
13 - 16 385 65 15 260 840 690 18 150 5.9 11.8 20.865 7.85
In inch
chain length diameter thickness length length length width take-up lashing proof minimum weight
size handle barrel open closed capacity load breaking each
position position load
a b c d e f g
inch inch inch inch inch inch inch inch inch t t t lbs
5 3 5 9 19 1 29 5 15 9 2.45 4.9 8.62 9.52
/16 - /8 15 /32 2 /16 /32 10 /32 28 /32 22 /8 /32 6 /32
3 1 5 9 19 1 29 7 5 1 4.175 8.35 14.97 12.63
/8 - /2 15 /32 2 /16 /32 10 /32 29 /32 23 /16 /8 6 /2
1 5 5 9 19 1 3 5 23 29 5.9 11.8 20.865 17.31
/2 - /8 15 /32 2 /16 /32 10 /4 33 /32 27 /32 /32 5 /32
