CHAIN CHAIN

Applications

Green Pin grade 8 and grade 10 steel chain can be
®
used for lifting. Green Pin Tycan Chain is available
®
as lifting and lashing chain. Short link and long link

commercial grade 3 chain is for general purpose use
and may not be used for lifting purposes.

Range

Green Pin supplies a wide range of chain. The range of grade 8 chain extends from 6 mm to 32 mm ( /4"
1
®
1
®
to 1 /4"). The range of grade 10 chain extends from 6 mm to 20 mm (7/32" to 3/4"). Green Pin Tycan Lifting
and Lashing Chain is available in sizes 11x15 mm, 11x20 mm, 15x25 mm and 13x30 mm. To complement the
®
Green Pin assortment, Van Beest also supplies chain to DIN 763 and DIN 766 ranging from 3 up to 20 mm.
Design
Grade 8 chain conforms to EN 818-2 and is made from alloy steel. Grade 10 chain is made from alloy steel
®
as well. Green Pin Tycan Chain is made from 100% Dyneema Fibre. Other chain supplied by Green Pin
®
®
generally follows DIN 763 (for long link chain) or DIN 766 (for short link chain). It is made of grade 3 mild steel.
These types of chain are not suitable for lifting purposes.
Finish

Both grade 8 and grade 10 steel chain are painted. Steel chain (DIN 763 and DIN 766) is available in self
coloured, electro-galvanized or hot dipped galvanized condition.

Instructions for use

DIN 766 and DIN 763 chain should be inspected before use to ensure that it is free from nicks, gouges
and cracks.
Also:
• DIN 766 and DIN 763 chain may not be used for lifting purposes;
• the chain is designed for in-line use only;
• the chain may not be heat treated, as this may affect performance.

Grade 8 and grade 10 chain should be inspected before use to ensure that:
12 • the chain is free from nicks, gouges and cracks;
• the item is not distorted or unduly worn.

Also:
• the chain may not be heat treated, as this may affect the performance;
• all components of the sling must be of the same steel grade;
• items should be used for in-line lifting only.

®
For complete Green Pin Tycan Lifting and Lashing Chain instructions, please refer to the user manuals in
INFO
the FAQ section on our website.
Chain must be regularly inspected in accordance with the safety standards given in the country of use. This
is required because the products in use may be affected by issues such as wear, misuse, and overloading,
which may lead to deformation and alteration of the material structure. Inspection should take place at least
every six months and more frequently when the chain is used in severe operating conditions.
