CHAIN Green Pin Tycan Lifting Chain
®
Lifting chain made from Dyneema
®
• Material:
made from 100% Dyneema ; layers of webbing in a Mobius twist with stitching
on each side ®
• Safety factor: MBL equals 4 x WLL
• Temperature range: -40°C to +70°C
• Certification: 2.1 2.2 MTC b DNV GL TQ CE

link working width thickness length links elongation weight layers
size load link link inside per meter at MBL per meter
limit
a b c
mm t mm mm mm % kg
11x15 2.6 15 11 100 10 5 0.32 6
11x20 4 20 11 100 10 5 0.47 6
15x25 5 25 15 100 10 5 0.58 8
13x30 6.8 30 13 125 8 5 0.75 7

FCHLIFT In inch

link working width thickness length links elongation weight layers
a
size load link link inside per meter at MBL per meter
limit
a b c
inch t inch inch inch % lbs
c
7 /16 x /32 2.6 19 /32 7 /16 4 10 5 0.70 6
19
b
7 25 4 25 7 4 10 5 1.04 6
/16 x /32 /32 /16
/32 x1 5 1 /32 4 10 5 1.28 8
19 19
1 3 6.8 3 1 59 8 5 1.65 7
/2 x1 /16 1 /16 /2 4 /64
INFO
Green Pin Tycan Lashing Chain
®
Lashing chain made from Dyneema ®

• Material: made from 100% Dyneema ; layers of webbing in a Mobius twist with stitching
®
on each side
• Safety Factor: MBL equals 2 x Lashing Capacity
• Temperature range: -60°C to +70°C
• Certification: 2.1 2.2 MTC b DNV GL TQ CE

link lashing width thickness length links elongation weight layers
size capacity link link inside per meter at MBL per meter
a b c
mm t mm mm mm % kg
15x25 10 25 15 100 10 5 0.58 8
12
In inch

link lashing width thickness length links elongation weight layers
FCHLASH size capacity link link inside per meter at MBL per meter

a b c
a inch t inch inch inch % lbs
19 /32 x1 10 1 19 /32 4 10 5 1.28 8

INFO
c
b
