Testing

Generally load rated products are Proofload tested, and certificates can be supplied upon request.
For specific information on certificates we refer to the separate paragraph on certification. SHACKLES
®
Green Pin shackles are Proofload tested at the following loads:
Green Pin Green Pin Green Pin ® Green Pin Green Pin Green Pin
®
®
Bow or Dee Super Shackles Sling Shackles Power Sling Web Sling BigMouth Dee
®
®
®
Shackles Shackle Shackle Shackle
Polar Shackles
®
Heavy Duty
Shackles
BigMouth
®
working load Bow Shackle
limit proof load proof load proof load proof load proof load proof load
t t t t t t t
0.33 0.66
0.5 1
0.75 1.5
1 2
1.5 3 1
2 4
3.25 6.5 8.13
3.3 6.6
4.6 9.2
4.75 9.5 11.88
5 10
6.5 13 16.25
7 14 14
8.5 17 21.25
8.6 17.2
9.5 19 19
12 24
12.5 25 25
13.5 27
15 30
15.5 31
16 32
17 34
18 36 36
21 42
25 50
30 60 60 60
35 70
40 80 80
42.5 85
55 110 110 110
75 150 112.5
85 170 170
120 240 240
125 187.5 250
150 225 225 225 300
175 262.5
200 300 300 400
250 375 375 500
300 450 450 600
400 600 532 800
500 750 665 1000
600 900 798 900
700 1050 931 1050
800 1200 1064 1200
900 1350 1197 1350
1000 1500 1330 1500
1250 1875 1663 1875
1500 2250
1550 2061.5 2325
