Green Pin Master Link S/S-GR5
STAINLESS STEEL PRODUCTS
®
Grade 5 stainless steel master link

• Material: AISI 316L, grade 5
• Safety factor: MBL equals 4 x WLL
• Finish: polished
• Temperature range: -40°C up to +200°C
• Certification: 2.1 2.2 3.1 MTC b

diameter diameter diameter working length width thickness weight
chain chain load inside inside each
1 leg 2 legs limit
a ß ≤ 45° ß ≤ 60° b c d
MSI mm mm mm mm t mm mm mm kg
13 6 6 6 1 110 60 6 0.34
16 8 6 8 1.25 110 60 6 0.53
c
18 10 8 10 2 135 75 8 0.82
22 13 10 13 3.2 160 90 10 1.45
26 16 13 16 5 180 100 13 2.29
a
b
In inch
diameter diameter diameter working length width thickness weight
chain chain load inside inside each
1 leg 2 legs limit
d
a ß ≤ 45° ß ≤ 60° b c d
inch inch inch inch t inch inch inch lbs
1 7 7 7 1 11 3 1 0.75
/2 /32 /32 /32 4 /32 2 /8 /4
5 5 7 5 1.25 11 3 1 1.17
/8 /16 /32 /16 4 /32 2 /8 /4
23 3 5 3 2 5 15 5 1.81
/32 /8 /16 /8 5 /16 2 /16 /16
7 1 3 1 3.2 5 3 13 3.20
/8 /2 /8 /2 6 /16 3 /4 /32
1 5 1 5 5 3 15 9 5.05
1 /32 /8 /2 /8 7 /32 3 /16 /16
