Green Pin Master Link Assembly S/S-GR5
®
Grade 5 stainless steel master link assembly

• Material: AISI 316L, grade 5
• Safety factor: MBL equals 4 x WLL
• Finish: polished
• Temperature range: -40°C up to +200°C
• Certification: 2.1 2.2 3.1 MTC b

diameter diameter working length width diameter length width thickness weight STAINLESS STEEL PRODUCTS
chain load inside inside inside inside each
2 legs limit
a ß ≤ 45° ß ≤ 60° b c d e f g
mm mm mm t mm mm mm mm mm mm kg
18 6 6 1.6 135 75 13 54 25 6 1.17
22 8 8 2.65 160 90 16 70 34 8 2.17
26 10 10 4.25 180 100 18 85 40 8 3.34
32 13 13 6.7 200 110 22 115 50 13 5.99
MTSI
In inch
c
diameter diameter working length width diameter length width thickness weight
chain load inside inside inside inside each
a 2 legs limit
b
a ß ≤ 45° ß ≤ 60° b c d e f g
inch inch inch t inch inch inch inch inch inch lbs
23 7 7 1.6 5 15 1 1 31 1 2.58
/32 /32 /32 5 /16 2 /16 /2 2 /8 /32 /4
g 7 5 5 5 17 5 3 11 5
/8 /16 /16 2.65 6 /16 3 /32 /8 2 /4 1 /32 /16 4.78
1 3 3 3 15 23 11 9 5
1 /32 /8 /8 4.25 7 /32 3 /16 /32 3 /32 1 /16 /16 7.36
1 1 1 6.7 7 11 7 17 31 1 13.2
1 /4 /2 /2 7 /8 4 /32 /8 4 /32 1 /32 /2

d
e

f
