Green Pin Omega Link S/S-GR5
®
STAINLESS STEEL PRODUCTS
Grade 5 stainless steel omega link

• Material: AISI 316L, grade 5
• Safety factor: MBL equals 4 x WLL
• Finish: polished
• Temperature range: -40°C up to +200°C
• Certification: 2.1 2.2 3.1

for chain working width diameter width length width length thickness width width thickness weight
diameter load pin inside bow outside outside outside each
limit
COI a b c d e f g h i j
mm inch t mm mm mm mm mm mm mm mm mm mm kg
5 3 /16 0.5 14 6 7 26 20 53 13 41 28 6 0.07
h
6 7 /32 0.7 14 8 7 25 20 53 13 41 28 6 0.07
h
a 7 - 8 1 /4 - /16 1.2 20 9 9 34 24 71 16 55 32 8 0.18
5
a 3
e 10 /8 1.6 19 13 12 40 31 82 17 63 42 11 0.28
d f
e 13 1 /2 2.7 25 16 15 51 40 106 20 84 54 14 0.64
d f
b
b c
i
c
g
i
g
j
j

Green Pin Connecting Link S/S-GR5
®
Grade 5 stainless steel connecting link

• Material: AISI 316L, grade 5
• Safety factor: MBL equals 4 x WLL
• Finish: polished
• Temperature range: -40°C up to +200°C
• Certification: 2.1 2.2 3.1

for chain working diameter width width length length diameter width weight
diameter load outside inside inside inside eye inside each
limit
MJI a b c d e f g
mm inch t mm mm mm mm mm mm mm kg
6 7 /32 0.7 8 42 11 20 52 11 15 0.09
b 1 5
c 7 - 8 /4 - /16 1.2 9 53 14 20 55 13 19 0.16
b
c 10 3 /8 1.6 10 66 18 23 64 18 23 0.28
13 1 /2 2.7 14 83 21 32 85 24 28 0.64
d
e d
INFO
e
g
a g
a

f
f
