Green Pin Sling Hook S S/S-GR5
®
STAINLESS STEEL PRODUCTS
Grade 5 stainless steel swivel sling hook

• Material: AISI 316L, grade 5
• Safety factor: MBL equals 4 x WLL
• Finish: polished
• Temperature range: -40°C up to +200°C
• Certification: 2.1 2.2 3.1 MPI b

• Note: equipped with a stainless steel washer
for chain working length length width width thickness width width length diameter thickness weight
diameter load inside inside opening outside outside each
limit
a b c d e f g h i j
mm inch t mm mm mm mm mm mm mm mm mm mm kg
CSEI 6 7 /32 0.7 100 33 32 26 15 20 72 164 12 6 0.55
7 - 8 1 /4 - /16 1.2 126 40 37 30 20 24 87 200 14 8 1
5
c 10 3 /8 1.6 159 47 47 33 24 29 106 250 16 11 1.9
13 1 2.7 189 59 58 37 32 39 133 307 21 14 3.42
i /2
j b

a h
d
f
e
g

Green Pin Grab Hook E S/S-GR5
®
Grade 5 stainless steel eye grab hook

• Material: AISI 316L, grade 5
• Safety factor: MBL equals 4 x WLL
• Finish: polished
• Temperature range: -40°C up to +200°C
• Certification: 2.1 2.2 3.1 MPI b

for chain working length inside inside opening thickness width width length width thickness weight
diameter load length width outside each
limit eye eye
CROI a b c d e f g h i j
mm inch t mm mm mm mm mm mm mm mm mm mm kg
6 7 /32 0.7 41 24 23 8 24 20 42 94 9 6 0.25
c
5
7 - 8 1 /4 - /16 1.2 53 27 26 10 33 23 53 115 10 8 0.32
c 10 3 1.6 65 38 36 12 40 29 66 146 14 10 0.53
j b /8
13 1 /2 2.7 83 42 41 15 56 40 88 183 16 12 1.96
j b
d h
a
d h
a
f
g f
i g
i

e
e
