Short link chain
Generally to DIN 766 and DIN 5685-3
• Material: AISI 316
• Standard: generally to DIN 766 and DIN 5685-3
• Certification: 2.1
diameter length width weight
inside outside per meter STAINLESS STEEL PRODUCTS
a b c
mm mm mm kg
3 16 11 0.17
4 16 14 0.32
5 18.5 17 0.5
R-7880 6 18.5 20 0.75
8 24 26 1.35
10 28 34 2.25
Long link chain
Generally to DIN 763 and DIN 5685-1
• Material: AISI 316
• Standard: generally to DIN 763 and DIN 5685-1
• Certification: 2.1
diameter length width weight
inside outside per meter
a b c
mm mm mm kg
3 26 12 0.14
4 32 16 0.27
5 36 20 0.43
6 42 24 0.63
7 48 28 0.86
R-7890 8 54 32 1.1
10 66 40 1.75
