Green Pin Dee Shackle FN
®
Standard dee shackle with safety bolt and fixed nut

• Material: bow and pin high tensile steel, grade 6, quenched and tempered SHACKLES
• Safety Factor: MBL equals 6 x WLL
• Standard: EN 13889, ASME B30.26 and meets performance requirements of US Fed. Spec.
RR-C-271 Type IVB Class 3, grade A
• Finish: hot dipped galvanized
• Temperature Range: -40°C up to +200°C
• Certification: 2.1 2.2 3.1 MTC a DNV GL 2.7-1 a DNV GL 2.7-1 b CE

working diameter diameter diameter width width length length length thickness securing securing torque weight
load bow pin eye eye inside inside bolt nut bolt bolt each
G-4133 limit thread length
a b c d e f g h i j k
t mm mm mm mm mm mm mm mm mm mm mm Nm kg
2 13.5 16 34 13 22 43 81 82 13 M6 35 8.4 0.39
3.25 16 19 40 16 27 51 97 98 17 M6 40 8.4 0.67
4.75 19 22 46 19 31 59 112 114 19 M6 45 8.4 1.08
6.5 22 25 52 22 36 73 134 130 22 M8 50 20 1.66
8.5 25 28 59 25 43 85 154 150 25 M8 55 20 2.46 1
9.5 28 32 66 28 47 90 167 166 27 M10 60 39 3.4
12 32 35 72 32 51 94 180 178 30 M10 65 39 4.51
13.5 35 38 80 35 57 115 209 197 33 M10 70 39 6.1
17 38 42 88 38 60 127 230 202 19 M8 75 20 7.63
25 45 50 103 45 74 149 271 249 23 M8 90 20 13.25
35 50 57 111 50 83 171 305 269 26 M10 100 39 18.53
42.5 57 65 130 57 95 190 345 301 29 M12 110 68 25.94
55 65 70 145 65 105 203 376 330 32 M12 120 68 35.33
85 75 83 162 73 127 229 427 380 39 M12 140 68 52.97
