Page 36 - Green Pin Product Catalogue 2019_EN

®
SHACKLES Green Pin Heavy Duty Dee Shackle BN
High load capacity dee shackle with safety bolt

• Material:
bow and pin alloy steel, grade 8 quenched and tempered
• Safety Factor:
MBL equals 5 x WLL
• Standard:
hot dipped galvanized
• Finish:
• Certification: ASME B30.26 a MPI a US a CE
2.1 2.2 3.1 MTC

working diameter diameter diameter width width length length length thickness weight
load bow pin eye eye inside inside bolt nut each
limit
a b c d e f g h i
G-6038 t mm mm mm mm mm mm mm mm mm kg
120 95 95 208 95 147 274 521 453 50 110
In inch
working diameter diameter diameter width width length length length thickness weight
1 load bow pin eye eye inside inside bolt nut each
limit
a b c d e f g h i
t inch inch inch inch inch inch inch inch inch lbs
120 3 /4 3 /4 8 /16 3 /4 5 /32 10 /32 20 /2 17 /32 1 /32 243
25
25
31
1
27
3
3
3
3
CAD RFID

36
