Page 37 - Green Pin Product Catalogue 2019_EN
P. 37
Green Pin Heavy Duty Dee Shackle FN
®
High load capacity dee shackle with safety bolt and fixed nut
• Material: bow and pin alloy steel, grade 8, quenched and tempered SHACKLES
• Safety Factor: MBL equals 5 x WLL
• Standard: ASME B30.26
• Finish: hot dipped galvanized
• Certification: 2.1 2.2 3.1 MTC a MPI a US a CE
working diameter diameter diameter width width length length length thickness securing securing torque weight
load bow pin eye eye inside inside bolt nut bolt bolt each
limit thread length
a b c d e f g h i j k
G-6018 t mm mm mm mm mm mm mm mm mm mm mm Nm kg
120 95 95 208 95 147 274 521 453 50 M12 150 68 110
In inch
working diameter diameter diameter width width length length length thickness securing securing torque weight
load bow pin eye eye inside inside bolt nut bolt bolt each 1
limit k thread length
a b c d e f g h i j k
j
t inch inch inch inch inch inch inch inch inch mm inch ft lb lbs
120 3 /4 3 /4 8 /16 3 /4 5 /32 10 /32 20 /2 17 /32 1 /32 M12 5 /32 50.1 243
1
25
25
29
31
27
3
3
3
3
k
j
37
