Green Pin Polar Bow Shackle FN
®
Grade 8 bow shackle with safety bolt and fixed nut for use under
low temperatures SHACKLES

• Material: bow and pin alloy steel, grade 8, quenched and tempered
• Safety Factor: MBL equals 7 x WLL
• Standard: EN 13889, ASME B30.26 and meets performance requirements of US Fed. Spec.
RR-C-271 Type IVA Class 3, grade A
• Finish: hot dipped galvanized
• Temperature range: -60°C up to +200°C
• Certification: 2.1 2.2 3.1 MTC a DNV GL 2.7-1 a DNV GL 2.7-1 b CE

G-5143 working diameter diameter diameter width width length width length length width thickness securing securing torque weight
load bow pin eye eye inside inside bow bolt nut bolt bolt each
limit thread length
a b c d e f g h i j k l m
t mm mm mm mm mm mm mm mm mm mm mm mm mm Nm kg
2 13.5 16 34 13 22 51 32 89 82 58 13 M6 35 8.4 0.42
3.25 16 19 40 16 27 64 43 110 98 75 17 M6 40 8.4 0.74
4.75 19 22 46 19 31 76 51 129 114 89 19 M6 45 8.4 1.18 1
6.5 22 25 52 22 36 83 58 144 130 102 22 M8 50 20 1.77
8.5 25 28 59 25 43 95 68 164 150 118 25 M8 55 20 2.58
m
9.5 28 32 66 28 47 108 75 185 166 131 27 M10 60 39 3.66
12 32 35 72 32 51 115 83 201 178 147 30 M10 65 39 4.91
l
13.5 35 38 80 35 57 133 92 227 197 162 33 M10 70 39 6.54
17 38 42 88 38 60 146 99 249 202 175 19 M8 75 20 8.19
25 45 50 103 45 74 178 126 300 249 216 23 M8 90 20 14.22
35 50 57 116 50 83 197 138 334 269 238 26 M10 100 39 19.85
42.5 57 65 130 57 95 222 160 377 301 274 29 M12 110 68 28.33
55 65 70 145 65 105 260 180 433 330 310 32 M12 120 68 39.59
85 75 83 162 73 127 329 190 527 380 340 39 M12 140 68 62
