Page 60 - Green Pin Product Catalogue 2019_EN

SHACKLES Green Pin Web Sling Shackle SC
®
Shackle for synthetic web slings with screw collar pin

• Material:
bow and pin alloy steel, grade 8, quenched and tempered
• Safety Factor:
MBL equals 6 x WLL
• Standard:
ASME B30.26
• Finish:
painted green
• Temperature Range: -40°C up to 200°C
• Certification: 2.1 2.2 3.1 CE

working diameter diameter diameter width width length width length length width weight
load bow pin eye eye inside inside inside bolt each
limit
P-5461 a b c d e f g h i j
t mm mm mm mm mm mm mm mm mm mm kg
3.25 20 19 40 16 27 38 35 87 89 68 0.66
j
4.75 24 22 46 19 31 48 46 106 103 85 1.1
6.5 27 25 52 22 36 72 62 137 119 109 1.79
8.5 31 28 59 25 43 84 79 158 137 134 2.79
1
In inch
working diameter diameter diameter width width length width length length width weight
load bow pin eye eye inside inside inside bolt each
limit
j
a b c d e f g h i j
t inch inch inch inch inch inch inch inch inch inch lbs
3.25 25 /32 3 /4 1 /16 5 /8 1 /16 1 /2 1 /8 3 /16 3 /2 2 /16 1.46
1
1
1
9
3
11
7
7
1
4.75 15 /16 7 /8 1 /16 3 /4 1 /32 1 /8 1 /16 4 /16 4 /16 3 /32 2.42
11
7
13
13
3
6.5 1 /16 1 2 /16 7 /8 1 /32 2 /32 2 /16 5 /32 4 /16 4 /32 3.95
13
7
1
1
9
27
11
13
9
13
7
1
7
8.5 1 /32 1 /8 2 /16 31 /32 1 /16 3 /16 3 /8 6 /32 5 /32 5 /32 6.04
5
1
5
11
