Green Pin Theatre Shackle SC
®
Matte black bow shackle with screw collar pin
• Material: bow and pin high tensile steel, grade 6, quenched and tempered SHACKLES
• Safety Factor: MBL equals 6 x WLL
• Standard: EN 13889 and meets performance requirements of US Fed. Spec. RR-C-271
Type IVA Class 2, grade A, from 2 t and upward these shackles comply with
ASME B30.26
• Finish: black
• Temperature Range: -40°C up to +200°C
• Certification: 2.1 2.2 3.1 MTC a CE
working diameter diameter diameter width width length width length length width weight
P-4161T load bow pin eye eye inside inside bow bolt each
limit
a b c d e f g h i j
t mm mm mm mm mm mm mm mm mm mm kg
0.33 5 6 12 5 9.5 22 16 36 29.5 26 0.02
0.5 7 8 16.5 7 12 29 20 48.5 38 34 0.05
0.75 9 10 20 9 13.5 32 22 56 46.5 40 0.1
1 10 11 22.5 10 17 36.5 26 63.5 54 46 0.14 1
1.5 11 13 26.5 11 19 43 29 74 59.5 51 0.19
2 13.5 16 34 13 22 51 32 89 73 58 0.36
3.25 16 19 40 16 27 64 43 110 89 75 0.63
4.75 19 22 46 19 31 76 51 129 103 89 1.01
6.5 22 25 52 22 36 83 58 144 119 102 1.5
8.5 25 28 59 25 43 95 68 164 137 118 2.21
In inch
working diameter diameter diameter width width length width length length width weight
load bow pin eye eye inside inside bow bolt each
limit
a b c d e f g h i j
t inch inch inch inch inch inch inch inch inch inch lbs
0.33 3 /16 1 /4 1 /2 3 /16 3 /8 7 /8 5 /8 1 /32 1 /32 1 /32 0.05
13
5
1
1
11
0.5 1 /4 5 /16 21 /32 9 /32 15 /32 1 /32 25 /32 1 /32 1 /2 1 /32 0.11
29
5
0.75 5 /16 3 /8 25 /32 11 /32 17 /32 1 /4 7 /8 2 /32 1 /32 1 /16 0.22
7
9
1
27
7
1
1
1 3 /8 7 /16 7 /8 13 /32 21 /32 1 /16 1 /32 2 /2 2 /8 1 /16 0.3
13
1
1.5 7 /16 1 /2 1 /32 7 /16 3 /4 1 /16 1 /32 2 /32 2 /32 2 0.42
5
29
11
1
11
2 1 /2 5 /8 1 /32 1 /2 7 /8 2 1 /4 3 /2 2 /8 2 /32 0.79
7
1
1
11
9
3.25 5 /8 3 /4 1 /16 5 /8 1 /16 2 /32 1 /16 4 /32 3 /2 2 /16 1.38
11
15
1
9
11
1
17
1
4.75 3 /4 7 /8 1 /16 3 /4 1 /32 3 2 5 /32 4 /16 3 /2 2.22
1
3
13
7
6.5 7 /8 1 2 /16 7 /8 1 /32 3 /32 2 /32 5 /32 4 /16 4 /32 3.31
1
9
9
1
13
11
21
5
13
8.5 1 1 /8 2 /16 31 /32 1 /16 3 /4 2 /16 6 /32 5 /32 4 /32 4.86
1
3
11
15
21
11
