SOCKETS SOCKETS

Applications

Sockets are used as a connection to attach steel wire
rope to a fixed point. This may be an anchoring system

for tubes or pipes, anchor wires for dredging materials,

anchor cables for oil platforms, fastening points for
towing cables or for fastening cables in constructions such
as bridges, roofs etc. Sockets are designed for in-line use only.

Sockets are the strongest steel wire rope end fittings available.

If they are assembled in the proper way they meet or exceed the
breaking strength of the steel wire rope.

Range

®
Green Pin offers a wide range of socket types in various sizes and shapes.
5
Design

Green Pin open- and closed spelter sockets and Green Pin open wedge sockets are made from cast high
®
®
tensile steel.
These sockets are generally marked with:
• manufacturer’s symbol - e.g. GP
7
• wire rope diameter in mm and inches - e.g. 20-22 and /8"
• traceability code - e.g. A01
• socket number - e.g. 104
Swage sockets are drop forged from special bar quality carbon steel C-1035 and spheroidized annealed
to make them suitable for cold swaging.

Finish

Green Pin open- and closed spelter sockets and open wedge sockets are galvanized. Swage sockets are
®
self coloured.
Certification

Specific details of certificate availability can be found on each product page. Please verify your certification
requirements at the time of order.

96
